Technical Specifications

  • Dimensions (L × W × H): 2696 × 915 × 1657 mm
  • Required Supporting Tractor Power: ≥ 108 kW
  • Ground Clearance (Axle Center Height): 1022 mm
  • Ground Contact Length: 2100 mm
  • Ground Contact Area: 3.84 m²
  • Compatible Models:
    • Case IH 6130
    • Case IH 6088
    • Claas 470
    • John Deere S660

Performance Features

  • Maximum speed: 35 km/h
  • Reduces ground pressure and improves vehicle passability
  • Simple structure, easy installation
  • Protects farmland and prevents soil compaction, supporting green agriculture
  • Under the same working conditions, track travel system reduces fuel consumption
  • Equipped with a self-adjusting hydraulic tensioning system
