Technical Specifications

  • Rated Power: 103 kW
  • Operating Weight: 7100 kg
  • Standard Traction Force: 32 kN
  • Maximum PTO Output Power: 88 kW
  • Overall Dimensions (L×W×H): 5250 × 2450 × 3130 mm
  • Minimum Ground Clearance: 450 mm
  • Wheelbase: 2688 mm
  • Half-Track Ground Contact Area: 1.8 m²
  • Track Width: 635 mm

Performance Features

  • Maximum speed: 40 km/h
  • Reduced ground pressure for improved vehicle passability
  • Full-time four-wheel drive design
  • Protects cultivated land and prevents soil compaction, supporting green agriculture
  • Reduces fuel consumption by 10%–30%, energy-saving and environmentally friendly
